Cyclone Dust Collector Introduction

Writer： admin Time：2019-03-19 11:31 Browse：℃

Cyclone dust collector, also called pneumatic cyclone separator, is a dust removal device which separates dust particles from the dust flow by using the centrifugal force generated by the rotating airflow, is generally used to collect particles above 5-15μm, and after improvement, the dust removal efficiency is more than 85%. It has the advantages of simple structure, small volume, low invest cost, the operation and maintenance is convenient, widely used in industrial factories



Technical parameter

SPECIFICATION(mm)	CAPACITY(m3/h)	INLET WIND SPEED（m/s）	EQUIPMENT EFFICIENCY(%)	WEIGHT（kg）
ψ1000	7750-9450	18-22	88-95	1050
ψ1250	11600-14200	18-22	88-95	2050
ψ1500	16750-20450	18-22	88-95	3000
ψ1750	23350-28500	18-22	88-95	3550
ψ2000	30050-36700	18-22	88-95	4250
