AUXILIARY EQUIPMENT
Chute Feeder
- Product ID：AUXILIARY EQUIPMENT
- Phone: +86-371-55091029
- Tel: +86 18538798892
- Email: sale@zzddjt.com
Interested? Leave a meassge for Tech and Price.
Introduction
Chute feederr is suitable for metallurgy, mining, insurance, engineering, construction, mineral processing, coal and other industrial sectors, transport bulk materials from storage silos to feeding device (not suitable for conveying powder materials).
Low-cost, high efficiency, long life, low energy consumption.
| Model |
mmW×H Outlet |
Max. granularity size mm |
Feed capacity m3/h |
E-motor |
Weight kg |
|
| Model | kw Power | |||||
| CG300×300 | 300×300 | 50 | 10~20 | Y90L-4 | 1.5 | 265 |
| CG400×400 | 400×400 | 100 | 10~25 | Y112-6 | 2.2 | 535 |
| CG600×500 | 600×500 | 200 | 10～50 | Y112M－6 | 4 | 1054 |
| CG700×500 | 700×500 | 250 | 10～60 | Y112M－6 | 4 | 1100 |
| CG1000×900 | 1000×900 | 300 | 10～70 | Y160M－4 | 7.5 | 1600 |
| CG1240×980 | 1240×980 | 350 | 40～90 | Y160M－6 | 7.5 | 1710 |
| CG1240×1100 | 1240×1100 | 400 | 61～150 | Y160M－4 | 11 | 1850 |
| CG1400×2000 | 1400×2000 | 300 | 50～101 | Y160M－4 | 11 | 3472 |
| CG2400×1200 | 2400×1200 | 350 | 120～150 | YCT225－4B | 15 | 3183 |
| CG2300×1400 | 2300×1400 | 300 | 250～500 | Y180M－4 | 18.5 | 6895 |
| Note: According to the user’s requirement, the motor can be changed into buncher,so as to adjust the feeding capacity. | ||||||
